Maple XCM Wheelset
Regular price $1,349.00 USDRegular priceUnit price per -
Maple XCO Wheelset
Regular price $1,349.00 USDRegular priceUnit price per -
Maple EMP Wheelset
Regular price $1,349.00 USDRegular priceUnit price per -
Maple XCR Wheelset
Regular price $1,499.00 USDRegular priceUnit price per
Ride Maple XCM
Our most popular wheelset is the XCM.
Versatile, strong, light, and in just the right 30mm internal width.
Wheelset Specs
ARX | CXG | RCX | RCT | G650 | XCR | XCO | XCM 29 | XCM 27.5 | EMP 29 | EMP 27.5 | |
Rim Weight (ea) | 255g | 360g | 420g | 460g | 385g | 290g | 360g | 440g | 425g | 470g | 455g |
i9 1/1 Set Weight | 1180g | 1442g | 1520g | 1600g | 1492g | 1292g | 1432g | 1592g | 1562g | 1652g | 1622g |
DT 350 Set Weight | 1163g | 1425g | 1503g | 1583g | 1490g | 1300g | 1440g | 1600g | 1570g | 1660g | 1630g |
i9 SOLiX/Hydra Set Weight | 1098g | 1360g | 1438g | 1518g | 1474g | 1284g | 1424g | 1584g | 1554g | 1644g | 1614g |
DT 240 Set Weight | 1094g | 1356g | 1434g | 1514g | 1402g | 1212g | 1352g | 1512g | 1482g | 1572g | 1542g |
DT 180 Set Weight | 1036g | 1298g | 1376g | 1456g | 1356g | 1166g | 1306g | 1352g | 1322g | 1412g | 1382g |
Diameter | 700c | 700c | 700c | 700c | 650b | 29 | 29 | 29 | 27.5 | 29 | 27.5 |
Spoke Count | 24h | 28h | 24h | 24h | 28h | 28h | 28h | 28h | 28h | 28h | 28h |
ERD | 589mm | 595mm | 569mm | 541mm | 554mm | 595mm | 595mm | 590mm | 550mm | 586mm | 548mm |
Offset | 2mm | 2mm | 0mm | 0mm | 2mm | 3mm | 2mm | 2mm | 2mm | 2mm | 2mm |
Internal Width | 24mm | 25mm | 21mm | 21mm | 27mm | 29mm | 25mm | 30mm | 30mm | 35mm | 35mm |
Depth | 25mm | 22mm | 35mm | 50mm | 23mm | 23mm | 22mm | 24mm | 24mm | 26mm | 26mm |
Tire Size | 25-50c | 25-50c | 25-50c | 25-50c | 2.0-2.4" | 2.2-2.6" | 2.0-2.4" | 2.2-2.6" | 2.2-2.6" | 2.4-3.0" | 2.4-3.0" |
Rider Weight Limit | 195lbs | 250lbs | 275lbs | 275lbs | 280lbs | 220lbs | 250lbs | 295lbs | 295lbs | 295lbs | 295lbs |
Wheelset weights are approximate and may differ due to variances in manufacturing, brake style choice, nipple choice, lacing options, etc.
